Spec. / Model | MU100GX | MU180GX | MU300GX | MU600GX | MU1200GX | |
Max. pumping speed *1 | 100m3/h (1,660L/min) | 180m3/h (3,000L/min) | 300m3/h (5,000L/min) | 600m3/h (10,000L/min) | 1,200m3/h (20,000L/min) |
|
Ultimate pressure *1 | 0.015mbar (1.5Pa) | 0.005mbar (0.5Pa) |
||||
Supply voltage (50/60Hz) | 200V model 400V model | 3Phase, AC200~240V *2 3Phase, AC380~440V *2 |
||||
Cooling water [L/min] | 1.5≧ | 2.0≧ | ||||
Power consumption [kW] *3 | 0.35 | 0.5 | 0.55 | 0.6 | 0.7 | |
Weight [kg] | 200V model 400V model | 60 65 | 95 (100) | 100 125 | 120 125 | 165 (170) |
Inlet size | NW50 | NW80 | NW100 | |||
Outlet size | W25 | NW40 | ||||
Dimensions [mm] W×H×L *4 | 200V model 400V model | 230×275×450 230×345×450 | 280×300×550 (280×350×580) | 230×520×450 230×575×530 | 230×520×530 230×575×530 | 275×580×625 (275×635×680) |
*1) Without N2 purge. *2) Contact us for other voltage options. *3) Approx. value at ultimate pressure. *4) Net size.
* Spec. & name of products are subject to change without prior notice.
* Contact us about large capacity pumps.
* Spec. & name of products are subject to change without prior notice.
* Contact us about large capacity pumps.
Please contact us for more information about specifications except standard models listed on this catalog.
- Because we are constantly working to improve performance and upgrade our products, specifications and diagrammatic representations in this catalog may change without notice.
- Products displayed in this catalog must be approved for export in accordance with the Foreign Exchange and Foreign Trade Control Act. Before placing an export order, please contact our Business Department.
